G652D St Upc To St Upc Fiber Optic Patch Cord 1M 3M 5M LSZH Jacket
G652D St Upc To St Upc Simplex Sm Fiber Optic Patch Cord 1M 3M 5M LSZH Jacket
Fiber Optic Patch Cord, ST/UPC to ST/UPC connector, Simplex SM(Single-Mode), single core, OD: Ф0.9MM/2.0MM/3.0MM Fiber Optic Cable is optional,Sheath Material:PVC OR LSZH is optional,Length: 1.5m,2m, 3m...is optional.
Features
1. High return loss:≥ 50dB
2. Low insertion loss:≤ 0.3dB
3. Exchangeability and Vibration:≤ 0.2dB
4. Operating Temperature:-40~75ºC
5. Storage Temperature:-40~85ºC
Application
1. Local ring net
2. Optical fiber sensor
3. Optical fiber test equipment
4. Optical fiber communication system
5. FTTH, LAN, PON & Optical CATV
| Product Name | ST ST Fiber Optic Patch Cord |
| Fiber Grade | SM G657A1/G652D/G657A2 |
| Connector Type | ST to ST |
| Wavelength | 1310/1550nm |
| Fiber Count | Simplex |
| Cable Jacket Diameter | 3.0mm/2.0mm |
| Cable Jacket Material | LSZH or PVC |
| Ferrule | UPC |
| Cable Length | 15 M or customized |
| Insertion Loss | ≤0.3dB |
| Return Loss | ≥50dB |
| Minimum Bend Radius | 10mm |
| Operation temperature | -40℃~ 85℃ |
Product Details
FAQ
Q1: What are the advantages of your price?
A1: We have our own factory, professioanl machinery equipment . We can meet the price advantage of
products with the same quality parameters, and we promise to achieve a price of 1%-10% lower than
that of our peers.
Q2: What is your quality advantage?
A2: We strictly according to the ISO9001 quality management system, insisting "Enough Cores,
Enough Meters, High Quality, High Performance". Providing our customers with higher quality
products and services.
Q3. Do you support customized brands?
A3: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the
logo free for bulk orders.
Q4: What are the benefits of working with you?
A4: New customers can enjoy AIXTON’s stock and annual year-end dividends, and support
long-term cooperative customers to upgrade to global agents and enjoy more discounted prices.
